- Camera
- Image Sensor2.0 megapixel progressive scan CMOS
- Max. Resolution1920 (H) Γ1080 (V)
- Min. Illumination0.005 Lux@(F1.6, AGC ON), 0 Lux with IR
- Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0Β° to 360Β°, Tilt: 0Β° to 90Β°, Rotation: 0Β° to 360Β°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.7 mm to 13.5 mm
- Focal Length & FOV102Β° to 31Β°
- Lens MountΦ 14
- Image
- Image Parameters SwitchSTD/HIGH-SAT
- Image SettingsBrightness, Sharpness, 3D DNR, Mirror, Smart IR
- Frame Rate
PAL: 1080p@25fps
NTSC: 1080p@30fps
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)β₯ 120 dB
- Image EnhancementYes
- White BalanceATW/MWB
- AGCHigh/Medium/Low
- Interface
- Video OutputTVI/AHD/CVI/CVBS
- General
- Material
Front cover: Metal
Main body: Plastic
Bracket: Metal
- Dimension84.5 mm Γ 92 mm Γ 255.1 mm (3.33" Γ 3.62" Γ 10")
- Weight
Approx. 648 g (1.43 lb.)
-A: Approx. 695 g (1.53 lb.)
- Operating Conditionβ-40 Β°C to 60 Β°C (-40 Β°F to 140 Β°F), humidity: 90% or less (non-condensation)
- CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
- LanguageEnglish
- Power Supply
12 VDC Β±25%
-A: 24 VAC Β±15%, 12 VDC Β±20%
*You are recommended to use one power adapter to supply the power for one camera.
- Consumption
Max. 7.7 W
-A: Max. 9.7 W
- IR RangeUp to 70 m
- Approval
- ProtectionIP67
