- Camera
- Image Sensor8.29 megapixel progressive scan CMOS
- Max. Resolution3840 (H) Γ 2160 (V)
- Min. IlluminationColor: 0.01 Lux@(F2.0, AGC ON), 0 Lux with IR
- Shutter Time
PAL: 1/12.5 s to 1/50,000 s
NTSC: 1/15 s to 1/50,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0Β° to 355Β°, Tilt: 0Β° to 75Β°, Rotate: 0Β° to 355Β°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Focal Length & FOVHorizontal FOV: 102.2Β° (2.8 mm), 79Β° (3.6 mm), 50.8Β° (6 mm)
- Lens MountM16
- Illuminator
- Supplement Light TypeIR
- Supplement Light RangeUp to 30 m
- Smart Supplement LightYes
- Image
- Image SettingsBrightness;Mirror;Sharpness;AGC
- Frame Rate
TVI: [email protected], 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps
CVI: [email protected], 8MP@15fps
AHD: [email protected], 8M@15fps
CVBS: 960H P/N
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementBLC;HLC
- Noise Reduction2D DNR
- White BalanceAuto/Manual
- Interface
- Video Output1 HD analog output;Switchable TVI/AHD/CVI/CVBS
- General
- Power
12 VDC Β±25%, max. 5.3 W
*You are recommended to use one power adapter to supply the power for one camera.
- MaterialMetal
- DimensionΦ 110.8 mm à 84.7 mm (Φ 4.4" à 3.3")
- WeightApprox. 495 g (1.09 lb.)
- Operating Condition-40 Β°C to 60 Β°C (-40 Β°F to 140 Β°F), humidity: 90% or less (non-condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Approval
- ProtectionIP67, IK10
