- Camera
- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) Γ 1080 (V)
- Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Angle AdjustmentPan: 0Β° to 360Β°, Tilt: 0Β° to 75Β°, Rotation: 0Β° to 360Β°
- Signal SystemPAL/NTSC
- Light AlarmSolid Light Alarm (White Light)
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 98Β°, vertical FOV: 51Β°, diagonal FOV: 115Β°
3.6 mm, horizontal FOV: 76Β°, vertical FOV: 41Β°, diagonal FOV: 90Β°
6 mm, horizontal FOV: 50Β°, vertical FOV: 27Β°, diagonal FOV: 58Β°
- Lens MountM12
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeUp to 20 m
- Smart Supplement LightYes
- Image
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
- Image SettingsBrightness, Mirror, Sharpness, Anti-Banding, AGC
- Frame Rate
TVI: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVBS: PAL/NTSC
- Day/Night ModeColor
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementDWDR, BLC, HLC, Global
- Noise Reduction3D DNR/2D DNR
- White BalanceAuto/Manual
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- MaterialPlastic
- DimensionΦ 85.02 mm à 81.25 mm (Φ 3.35" à 3.2")
- WeightApprox. 161 g (0.36 lb)
- Operating Condition-40Β°C to 60Β°C (-40Β°F to140Β°F), Humidity: 90% or less (non-condensing)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power
12 VDC Β± 25%, Max. 2.4 W
*You are recommended to use one power adapter to supply the power for one camera.
