- General
- ShellMetal material, fan-free design
- Net Weight1.3 kg (2.9 lb)
- Gross Weight1.9 kg (4.2 lb)
- Dimensions (W × H × D)440.00 mm × 44.00 mm × 160.00 mm (17.32'' × 1.73'' × 6.30'')
- Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Relative Humidity5% to 95% (no condensation)
- Power Supply100-240 VAC, 50/60 Hz, Max. 0.3 A
- Max. Power Consumption12 W
- Power Consumption in Idle2.8 W
- Installation ModeRack (equipped with mounting ears)
- Surge Protection6 KV
- Network Parameters
- Ports16 × Gigabit RJ45 port
- MAC Address Table8 K
- Switching Capacity32 Gbps
- Packet Forwarding Rate23.81 Mpps
- Internal Cache4.1 Mbits
- Approval
- EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),RCM (AS/NZS CISPR 32: 2015)
- SafetyCE-LVD (EN 62368-1: 2014+A11: 2017),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition)
- ChemistryCE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
