Description
With a highly integrated design, JC400P EdgeCam 2 comes with a 080P front camera that records everything on the road and in the cabin. The JC400P 4G dashcam enables you to get a more complete view of the situation in case of an accident or emergency, day or night.
| Specification | |
| Network | |
| Standard | 4G LTE Cat.4 |
| WiFi | 2.4GHz, Support AP Mode/STD Mode/WiFi Direct |
| Bluetooth | BLE 4.0 |
| Band | Eurasian Version LTE-FDD: B1/B3/B5/B7/B8/B19/B20 LTE-TDD: B38/B39/B40/B41 (100M) WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 |
| American Version LTE-FDD: B2/B3/B4/B5/B7/B12/B17 LTE-TDD: B38/B41 (100M) WCDMA: B2/B4/B5 GSM: B2/B5/B8 |
|
| Camera | |
| Front Camera (Main) | 1920×1080/25FPS/F2.2/Full color/118° (HFoV) |
| Sub Camera | 1280×720/15FPS/F2.5/Full color in daytime & monochrome in dim light/90° (HFoV) |
| Video Format | .mp4 |
| Configuration | |
| GNSS | GPS/BDS |
| Sensor | 6-axis |
| Microphone | Support |
| Speaker | Support |
| Interface | Micro USB*1, SOS*1, RS232*1, Relay*1 |
| Memory Support | TF card (Up to 256GB) |
| SIM Card Type | Nano |
| LED Indication | Red (Power), Blue (Cellular), Green (GNSS) |
| Others | |
| Power Supply | Power cable: B+/ACC/GND |
| Operating Voltage | DC 9–30V |
| Operating Temperature | –20°C to +65°C |
| Storage Temperature | –30°C to +85°C |
| Device Weight | 233g |
| Device Dimension | 109*69*52mm |
| Certifications | CE/FCC/RoHS |
* We reserve the right to the final interpretation for this product. All information is for reference only and is subject to change without further notice.
