Description
Name : MixPad X Pro Panoramic Smart Voice Screen
Product specifications: 317*141*13mm (not including the thickness of the bottom box of the power supply)
Memory: 2G+8G
Light perception: support
Communication method: Zigbee 3.0, Bluetooth 5.1, Wi-Fi 2.4 GHz and 5 GHz, Ethernet
Main control: Quad-core Cortex-A55 architecture CPU, 2.0 GHz
LCD screen: 12.3 inches IPS car grade touch screen
Speaker: AAC Box speaker 2W*4
Power input: DC12V 2.5A adapter power supply
Working environment: 0~50℃, humidity ≤90%RH
Storage environment: -20~75°C, humidity ≤95%RH
Mixpad S Basic parameters
220v zero firewire protocol: Zigbee/wifi/wifi/Bluetooth Bluetooth large access: 255 pieces: 4-inch inch support supports two outputs Remote/local remote: integrated off-network: integrated integrated integrated gateway, voice speaker temperature and humidity monitoring background music host, scene panel, fresh air control, and other whole-house control center functions.
Installation
1. Pre-embed a national standard 86 bottom box, the depth is ≥ 5cm
2. It is foreseeable to add a bottom box to install the hidden switch, and the center distance between the two bottom boxes is 87mm
3. The mixing board is installed horizontally, and 86 bottom boxes are arranged with screws. The bit needs to be on the farthest side, the most side of the button
4. Recommended installation height (height from the ground): 1.35m
5. Use WiFi to connect to the Internet, and there needs to be WIFI wireless network coverage near the device
Wiring scheme
1. Reserve 220V power supply zero live wire
2. Reserve 2 circuit light control lines
