| Basic |
| Rated Power |
7 kW |
11 kW |
22 kW |
| Power Supply |
AC230 V±15%
50/60 Hz
1-Phase |
AC400 V±15%
50/60 Hz
3-Phase |
AC400 V±15%
50/60 Hz
3-Phase |
| Input Cable Wiring Method |
L1/N/PE |
L1/L2/L3/N/PE |
L1/L2/L3/N/PE |
| Operating Current |
32 A max |
3 * 16 A max |
3 * 32 A max |
| Socket Outlet or Connector Type |
Socket/5 m (16.40 ft) Cable, Type 2 |
| Charging Protocol |
Mode 3 (EN/IEC 61851) |
| Protection |
IP66 (Cable), IP55 (Socket) |
| Anti-collision Grade |
IK10 |
| Operating Temperature |
–30 °C to +50 °C (– 22 °F to +122 °F) |
| Storage Temperature |
–40 °C to +70 °C (–40 °F to +158 °F) |
| Port |
| Charging Port |
Type 2 (Socket, IEC 62196 Type2 EU) |
| Ethernet Port |
1 × RJ-45 port |
| Others |
RS485*2/CAN*2/USB |
| Function |
| Charging Control Mode |
Plug & Play/RFID/APP |
| Communication Protocol |
OCPP 1.6J and ModBus TCP |
| Upgrade Method |
USB upgrade and remote upgrade (OCPP 1.6J) |
| DLB |
Supports Dynamic Load Balancing and solar charging. |
| Leakage Protection |
30 mA Type A RCD + 6 mA DC |
| Security Protection |
Surge protection, over temperature protection, over voltage protection, under voltage protection, over current protection, grounding protection, electrical leakage protection, PEN (for British regions), and Integral 30 mA Type A RCD (EN 61008) + 6 mA DC protection (EN 62955) |
| General |
| Operating Humidity |
≤95% (RH), non-condensing |
| Product Dimensions |
443.0 mm × 273.0 mm × 171.5 mm (17.44" × 10.75" × 6.75") (H × W × D) |
| Packaging Dimensions |
cable: 606.0 mm × 423.0 mm × 484.0 mm (23.86" × 16.65" × 19.06") (L × W × H)
socket: 606.0 mm × 423.0 mm × 409.0 mm (23.86" × 16.65" × 16.10") (L × W × H) |
| Net Weight |
6.0 kg ± 0.5 kg (13.23 lb ± 1.10 lb) |
| Package Weight |
12.0 kg ± 1.0 kg (26.46 lb ± 2.20 lb) |
| Installation Environment |
Indoor or outdoor in well-ventilated places and free of oil stains, chemicals and inflammable and explosive substances. |
| Installation |
Wall mount and vertical pole mount |
| Wire |
Wire cross-section:
3 × 6 mm2 (9 AWG) 1-Phase
5 × 6 mm2 (9 AWG) 3-Phase |
| Certifications |
CE/CB
EN IEC61851-1, EN IEC61851-21-2, EN300328, EISI EN300330,
EN301489-1/-17/-3/-52, EN62311, EN50364, ETSI EN 301511,
ETSI EN301908-1/-2/-13, IEC62955, 2011/65/EU, 2015/863/EU |
