Hikvision/Mifare/1Card Reader

Call for Price

Description

Hikvision DS-K1101M Mifare Card Reader



  • PC+ABS material shell with PMMA panel design
  • Equipped with the 32-bit high-speed processor
  • Built-in audible beeper
  • Display the reader status with LED indicator
  • DIP switch
  • RS485 and Wiegand(W26/W34) protocol
  • Tamper-proof alarm
  • Online upgrade function(under the 485 communication mode), and card reader can degrade to pre-upgrade status in case of upgrading failed
  • Watchdog design for repairing itself in case that exception occurs, to ensure the long service life of the reader
  • Dust-proof and water-proof design
  • Read Mifare card and obtain the card No.
Power Supply12V DC
Working Current≤500mA
Processor32-bit
Reading Frequency13.56MHz
Reading Range≤50mm (≤1.97″)
ID Settingsvia DIP Switch
Audio AlertBeeper
Power Consumption≤2W
KeypadNo Keypad
CertificationsFCC, CE
LED IndicatorPower Indicator; Status LED Indicator
Working Temperature-20°C to +65°C (-4°F to +149°F)
Working Humidity10% to 90% (Non Condensing)
Protection LevelIP 64
Dimensions132.0mm × 92.3mm × 20.5mm (5.20” × 3.63” × 0.81″)
Weight≤0.14Kg
Installing MethodApplied for 120 Gang Box Only
